Product Description -
Summary - Excellent condition, working perfectly. With the original outer box but the internal box / leaflets / adapters etc aren't included. Specifications below -
Graphics Processor
- GPU Name
- AD102
- GPU Variant
- AD102-300-A1
- Architecture
- Ada Lovelace
- Foundry
- TSMC
- Process Size
- 5 nm
- Transistors
- 76,300 million
- Density
- 125.3M / mm²
- Die Size
- 609 mm²
Graphics Card
- Release Date
- Sep 20th, 2022
- Availability
- Oct 12th, 2022
- Generation
- GeForce 40
- Predecessor
- GeForce 30
- Production
- Active
- Bus Interface
- PCIe 4.0 x16
Clock Speeds
- Base Clock
- 2235 MHz
- Boost Clock
- 2520 MHz
- Memory Clock
- 1313 MHz
21 Gbps effective
Memory
- Memory Size
- 24 GB
- Memory Type
- GDDR6X
- Memory Bus
- 384 bit
- Bandwidth
- 1,008 GB/s
Render Config
- Shading Units
- 16384
- TMUs
- 512
- ROPs
- 176
- SM Count
- 128
- Tensor Cores
- 512
- RT Cores
- 128
- L1 Cache
- 128 KB (per SM)
- L2 Cache
- 72 MB
Theoretical Performance
- Pixel Rate
- 443.5 GPixel/s
- Texture Rate
- 1,290 GTexel/s
- FP16 (half)
- 82.58 TFLOPS (1:1)
- FP32 (float)
- 82.58 TFLOPS
- FP64 (double)
- 1,290 GFLOPS (1:64)
Board Design
- Slot Width
-
Triple-slot
Quad-slot
- Length
-
304 mm
348 mm12 inches
13.7 inches
- Width
-
137 mm
160 mm5.4 inches
6.3 inches
- Height
-
61 mm
73 mm2.4 inches
2.9 inches
- TDP
- 450 W
- Suggested PSU
- 850 W
- Outputs
-
1x HDMI 2.1
3x DisplayPort 1.4a
2x HDMI 2.1
3x DisplayPort 1.4a
- Power Connectors
- 1x 16-pin
- Board Number
- PG139 SKU 330
Graphics Features
- DirectX
- 12 Ultimate (12_2)
- OpenGL
- 4.6
- OpenCL
- 3.0
- Vulkan
- 1.3
- CUDA
- 8.9
- Shader Model
- 6.7
AD102 GPU Notes
| Ray Tracing Cores: 3rd Gen Tensor Cores: 4th Gen NVENC: 8th Gen NVDEC: 5th Gen PureVideo HD: VP12 VDPAU: Feature Set L |
This card has passed several tests. Including a run on each of Unigene’s Heaven and Superposition benchmarks (for performance figures in relation to brand new models) and we only buy cards in once they pass all the tests we put them through. Finally, we perform a visual check to ensure it’s in good enough aesthetic condition, although with a brand new card that’s fairly obviously going to be okay!!
All our cards are in good working condition as explained above. However, if you receive your order and it unfortunately doesn’t work, don’t panic, we have a 30 day return window, with money back guarantee. All so you can enjoy the bargain without being worried about any issues.
Here's the GPUsed product grading system (currently only in place for GPUs)
A+ - New or Like new
A - Excellent / Very good for a used item (our most common grade)
B - Working (may have some cosmetic issues but won't affect performance)
C - Non working (we don't currently sell non working hardware)
